WLD-3 / 1500W / JPT - $1,808.00
- WLD-3 / 1500W / JPT - $1,808.00
Factory Price Laser Welding Machine 3000w Electric Laser Welding Machine 4in1 Copper-gold Welding Laser
PRODUCT DETAILS
|
Device parameters
|
|||
|
Unit type
|
WLD-1500W
|
||
|
Maximum laser power
|
1500W
|
2000W
|
|
|
The laser wavelength
|
1064nm
|
||
|
Condenser reflector
|
Imported ceramic condenser
|
||
|
The laser frequency
|
1-20Hz
|
||
|
The pulse width
|
0.1-10Ms
|
||
|
Spot adjustment range
|
0.3-2mm
|
||
|
Aimed at positioning
|
Microscope (optional camera system)
|
||
|
The engine power
|
8KW
|
||
|
Demand for electricity
|
380V±5V 50Hz/40A /220V±5V 50Hz/60A
|
||
|
Range of three dimensional load-bearing table
|
125×100×300mm
|
||
|
bearing capacity of three dimensional load-bearing table
|
150kg
|
||
|
Manual suspension arm
|
Lifting height
|
600mm
|
|
|
stretch scope
|
3m
|
||
|
External dimensions/net weight
|
Host computer: 1000×550×1150mm
|
103kg
|
|
|
|
Three dimensional load-bearing table: 550×400×700mm
|
57kg
|
|
|
|
Manual suspension arm: 1050×1250×1700mm
|
147kg
|
|
Product Details
1. Adopt imported ceramic concentrating cavity, high reflectivity, strong energy, high temperature resistance, corrosion resistance and long service life;
2. equipped with 1.5P special chiller, can meet the long-term, high-power welding stability;
3.The base of the workbench is electrically lifted and lowered. The workbench moves using precision ball screw and high-precision straight guide rail. It is light and flexible, with precise positioning and bearing capacity up to 200 kg.
4. the laser head can slide back and forth, manual lifting, the laser head can be easily rotated 180 degrees, convenient to repair any side;
5. remote control all-round control, 360 degree flexible adjustment of welding angle position, suitable for all kinds of mold welding, for large molds, you can use the workbench, directly on the ground or forklift for mold welding, you can repair the welding radius of 1.5 meters, the weight of the number Tons of large molds and equipment The spare pulley is convenient to move, and can be moved directly to the injection molding machine to directly repair the welding without removing the mold;
6. the welding depth is large,the welding is more firm, the welded part can be fully melted without pores and trachoma, and the repair marks are neat and
beautiful.
beautiful.
Laser source MAX/RAYCUS/JPT
With the longer service life of the third-generation fiber laser, the equipment is not afraid of the optical path changes caused by movement; it is suitable for long-term processing;
Device Configuration
1. A set of laser source（MAX/JPT/Raycus）; 2. A set of laser power supplies; 3. A set of optical systems; 4. A set of movable and movable optical benches; 5. A set of liquid crystal display systems; 6. A set of refrigeration and water flow water temperature detection and protection systems; 7. One microscope; 8. A set of workbenches;
